MCR07-GH OEM RFID & HMI Operator Panel

MCR07-GH is a multi-purpose, programmable OEM RFID & HMI & Telemetry terminal usable in the areas such as Telemetry & IoT, RFID & HMI and Automation etc. It supports rich communication technologies such as GPRS/NB-IoT/Wi-Fi/Bluetooth over Ethernet and Mini PCIe expansion slots. Compared to MCR08-GH series, it has 7” TFT touchscreen and a more powerful processor. It is an OEM terminal especially developed for RFID & HMI Operator Panel applications.


Specifications:

  • 7” TFT Capacitive/Resistive Touchscreen

  • 13.56 MHz NFC/RFID Reader and 50Ω External Antenna

  • Ethernet and GPRS/2G/3G/LTE/NB-IoT or Wi-Fi & Bluetooth

  • RS232/RS485 ModBus & Internal Relay & Digital Input

  • Power Over Ethernet (PoE) and Easy Configuration

  • Source Code and Software Development Kit for System Integrators

TECHNICAL SPECIFICATIONS

READ-WRITE

ISO14443A/B

MIFARE® Classic, DESFire/Plus and Ultralight Contactless Card Read/Write

ISO/IEC 15693*

ISO/IEC 18000* (ICODE®)

50Ω External RFID Antenna Output Port

DISPLAY

7" TFT Capacitive/Resistive Touchscreen LCD Display

PROCESSOR

32-bit ARM Cortex 200 MHz High Performance CPU

MEMORY

8 GB Internal microSD Memory

1 MB Internal NOR Flash Memory

256 KB FRAM*

COMMUNICATION

Ethernet 10/100 Mbps

Integrated TCP/IP ( UDP,ICMP, FTP, NTP, Ping ) Software Cluster

Internal GSM/GPRS 2G/3G/LTE/NB-IoT miniPCIe Modem*

Internal Wi-Fi IEEE 802.11 b/g/n / Bluetooth BLE 4.2 miniPCIe Modem*

RS232 Port (300-115200 Baud)

RS485 Port (300-115200 Baud)

USB 2.0 (VCOM, HID)

INPUT/OUTPUT

2x Relay Outputs (1.5A Dry Contact)

4x Optically-Isolated Digital Inputs

ADDITIONAL SPECIFICATIONS

Offline Operation Mode

Internal Real Time Clock (RTC)

Real Audio Output (Internal Amplifier and Loudspeaker)

4 LED Indicators

Buzzer Audio Alert

Holes for Panel Installation

POWER

6-60V DC Operating Voltage

IEEE 802.3af PoE*

ENVIRONMENTAL CONDITIONS

-20°C … +70°C Industrial Operating Range

-30°C … +80°C Storage Range


* = Optional
